| Transmission rate |
0~100Mbps |
| Transmission distance |
fiber 0~20km/80km |
| Signal data interface |
GH1.25 |
| End to end connector |
FC/APC Connector |
| Data format |
TTL/SBUS |
| Input voltage |
9~28V |
| Size |
65*38*9mm |
| Weight |
25g |
| Shell material |
aluminum alloy |
| Fiber wavelength |
1310/1550nm |
| Optical fiber housing material |
abs |
| Optical fiber specification |
0.3mm |
| Optical fiber interface |
FC interface |
| Fiber type |
Single-mode fiber |
| Sensor |
1/2.8-inch image sensor |
| EFL |
1.90mm |
| View Angle |
D=131°H=121°V=82 |
| F.NO |
f/2.2 |
| Measuring Distance |
0.45 meters |
| Video standard |
NTSC/PAL/SECAM |
| Data direction |
bidirectional |
| Resolution |
Backward compatible up to 4K30fps |
| Encoding mode |
H.265/H.264 Configurable |
| Video bit rate |
500kbps~15Mbps adiustable |
| Transport protoco |
RTMP, RTSP, TS |
| Operating temperature |
-40℃~+70℃ |
